RX100 S7
Upgrade and Maintenance Manual 221
Expansion cards and backup units
9.4.6 Replacing an expansion card in riser module 2
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 43.
Note on network settings recovery
The following notes are required for RX100 S7p (PYR10Pxxx for Japanese
market).
I When replacing network controllers or the system board, network
configuration settings in the operating system will be lost and replaced
by default values. This applies to all static IP address and LAN teaming
configurations.
Ensure to note down your current network settings before replacing a
network controller or the system board.
9.4.6.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Main steps:
– slot 2: tool-less
– slot 1: Phillips PH2 / (+) No. 2 screw driver
9.4.6.2 Preliminary steps
Ê Perform the following procedures:
1. "Opening the rack door" on page 59
2. "Locating the defective server" on page 55
3. If applicable, ensure to note down your current network settings in the
operating system.
Upgrade and Repair Units (URU)
Additional task duration for FW update: 5 minutes
Average task duration: 10 minutes
