Fujitsu PRIMERGY RX100 S7 - Removing the Defective SATA Cable

410 Upgrade and Maintenance Manual RX100 S7
Cables
5. "Opening the server" on page 64
16.7.3 Removing the defective SATA cable
Figure 292: Disconnecting the SATA cables from the SAS/SATA backplane
Ê Disconnect the SATA cable from the SAS/SATA backplane.
Figure 293: Disconnecting the SATA cable from the system board
Ê Disconnect the SATA cable from the system board.
Ê Remove the SATA cable.
