RX100 S7
Upgrade and Maintenance Manual 297
12 Optical disk drive
12.1 Position of the ODD bay
Figure 194: Position of the ODD bay
You can install a 5.25-inch slimline optical disk drive (ODD) in the left bottom
side bay.
12.2 Installing the ODD
V CAUTION!
●
Before installing/removing an accessible drive to/from the server, turn
off the server, all peripheral devices, and any other connected
devices. Also unplug all power cables from the outlet. Failure to do so
can cause electric shock.
●
When installing an accessible drive, hold it by the side. Applying force
to the top may cause failures.
●
Do not touch the circuitry on boards and soldered parts. Hold the
metallic areas or the edge of the circuit boards.
●
The circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Before handling them, first
touch a metal part on the server to discharge static electricity from
your body.
Upgrade and Repair Units (URU)
Average task duration: 5 minutes
