RX100 S7
Upgrade and Maintenance Manual 331
Management and diagnostics modules
14.3.1.7 Connecting the front LAN cable to the front LAN card
I The front LAN card is already mounted in its holder.
Figure 223: Routing the front LAN cable
Ê Route the front LAN cable as shown in the photo.
