RX100 S7
Upgrade and Maintenance Manual 441
Cables
5. "Opening the server" on page 64
16.12.3 Removing the defective power cable
Figure 332: Disconnecting the power cables
Ê Disconnect the defective power cable (1) or (2) from the power distribution
board and the system board.
/
