420 Upgrade and Maintenance Manual
RX100 S7
Cables
16.9.9 Connecting the new cable to the front VGA/LAN
module
Figure 306: Connecting the cables to the front VGA/LAN module
Ê Connect the front LAN cable (1) or the front VGA cable (2) to the front
VGA/LAN module.
/
