Fujitsu PRIMERGY RX100 S7 - Removing the Front LAN Card; Removing the Riser Module 1

416 Upgrade and Maintenance Manual RX100 S7
Cables
5. "Opening the server" on page 64
16.9.3 Removing the riser module 1
Figure 300: Removing the riser module 1
Ê Carefully pull out the riser module 1 upward.
16.9.4 Removing the front LAN card
Figure 301: Removing the front LAN card
A
A
/
0
/
