RX100 S7
Upgrade and Maintenance Manual 367
System board and components
Ê Under Pending TPM operation, select the desired TPM operation
mode.
Ê Save your changes and exit the BIOS.
I For detailed information on how to access the BIOS and modify
settings, refer to the "System Board D3034 BIOS Setup Utilty"
reference manual available online at http://manuals.ts.fujitsu.com
(http://jp.fujitsu.com/platform/server/primergy/ manual/ for the
Japanese market) or from the ServerView Suite DVD 2 supplied
with your PRIMERGY server.
15.3.2 Removing the TPM
V CAUTION!
Advise your contact persons that they must provide you with TPM
backup copies. For security reasons, the TPM must be restored/re-
saved by the customer. After installing a new system board, the TPM
must be enabled. You may not clear the TPM data.
If the contact persons DO NOT have a backup copy available, inform
them that removing the TPM will cause to lose all data.
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 43.
15.3.2.1 Required tools
●
Preliminary and concluding steps: Phillips PH2 / (+) No. 2 screw driver
●
Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
●
Removing the TPM:
– Thin slotted screw driver (2 x 0.4 mm)
Field Replaceable Units (FRU)
Average task duration: 30 minutes
