116 Upgrade and Maintenance Manual
RX100 S7
Power supply
6.2.10 Installing the dummy cover
Figure 33: Dummy cover
Figure 34: Installing the dummy cover
Ê Push the dummy cover into the right bay until it clicks into place.
Ensure that the marking "TOP" is right and the upper rear cant of the dummy
cover fits under the PSU cage.
