RX100 S7
Upgrade and Maintenance Manual 245
Expansion cards and backup units
9.5.2 Installing the FBU
V CAUTION!
●
Do not connect the cable using excessive force, the connector is
weak.
●
Follow the safety instructions in chapter "Important information" on
page 43.
9.5.2.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Installing FBU: tool-less
●
Installing TFM: Phillips PH1 / (+) No.1 screw driver
9.5.2.2 Preliminary steps
Ê Perform the following procedures:
1. "Opening the rack door" on page 59
2. "Disabling SVOM boot watchdog functionality" on page 76
3. "Shutting down the server" on page 59
4. "Extending/removing the server from the rack" on page 60
5. "Opening the server" on page 64
Upgrade and Repair Units (URU)
Average task duration: 15 minutes
