230 Upgrade and Maintenance Manual
RX100 S7
Expansion cards and backup units
9.4.9 Replacing a riser card in riser module 2
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 43.
9.4.9.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Main steps:
– slot 1: Phillips PH2 / (+) No. 2 screw driver
– slot 2: Phillips PH2 / (+) No. 2 screw driver
9.4.9.2 Preliminary steps
Ê Perform the following procedures:
1. "Opening the rack door" on page 59
2. "Locating the defective server" on page 55
3. "Shutting down the server" on page 59
4. "Extending/removing the server from the rack" on page 60
5. "Opening the server" on page 64
6. "Locating the defective component" on page 58
9.4.9.3 Removing the riser module 2
Ê Remove the riser module 2 as described in section "Removing the riser
module 2" on page 213.
Field Replaceable Units (FRU)
Average task duration: 5 minutes
