RX100 S7 Upgrade and Maintenance Manual 459
Appendix
17.3 Settings system board
17.3.1 Jumper
Figure 347: Jumper
Jumper Print Setting
J22 PASSWORD SKIP open: normal operation (default)
short: clear password and apply the default
BIOS settings
J26 BIOS RECOVER 1-2 normal operation (default)
2-3 recovery mode
SATA4
SATA2
SATA1
SATA3
PCH
SATA5-ODD
Riser card (x1)
DIMM1B
DIMM2A
DIMM1A
DIMM2B
VGA
Riser card (x4)
USB1/2
Standard
LAN
UFM
USB3/4
Slot2
Slot1
FAN SYSFRONT VGA FRONT PANEL
J22
J26
Reset (PIN1),
GND (PIN2)
1
Default:
J22
J26
Indicate
CSS
CSS
