Fujitsu PRIMERGY RX100 S7 - Connecting Cables to the Expansion Card; Installing the Expansion Card; Installing the Riser Module 2

RX100 S7 Upgrade and Maintenance Manual 233
Expansion cards and backup units
Figure 141: Installing the riser card - slot 1
Ê Insert the riser card (1).
Ê Fasten the riser card with two screws (2).
9.4.9.7 Installing the expansion card
Ê Install the expansion card as described in section "Installing the expansion
card" on page 205.
9.4.9.8 Connecting cables to the expansion card
Ê If necessary, connect the cables to the expansion cards as described in
section "Connecting cables to the expansion card" on page 207.
9.4.9.9 Installing the riser module 2
Ê Install the riser module 2 as described in section "Installing the riser module
2" on page 207.
