Fujitsu PRIMERGY RX100 S7 - Disconnecting the Cables from the ODD; Preliminary Steps

RX100 S7 Upgrade and Maintenance Manual 303
Optical disk drive
12.3.2 Preliminary steps
Ê Perform the following procedures:
1. "Opening the rack door" on page 59
2. "Removing backup and optical disk media" on page 77
3. "Disabling BitLocker functionality" on page 75
4. "Shutting down the server" on page 59
5. "Extending/removing the server from the rack" on page 60
6. "Opening the server" on page 64
12.3.3 Disconnecting the cables from the ODD
Figure 200: Disconnecting the cables from the ODD
Ê Disconnect the fan/ODD power cable (1) from the ODD.
Ê Disconnect the SATA cable (2) from the ODD.
/
