302 Upgrade and Maintenance Manual
RX100 S7
Optical disk drive
12.3 Removing the ODD
V CAUTION!
●
Before installing/removing an accessible drive to/from the server, turn
off the server, all peripheral devices, and any other connected
devices. Also unplug all power cables from the outlet. Failure to do so
can cause electric shock.
●
When installing an accessible drive, hold it by the side. Applying force
to the top may cause failures.
●
Do not touch the circuitry on boards and soldered parts. Hold the
metallic areas or the edge of the circuit boards.
●
The circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Before handling them, first
touch a metal part on the server to discharge static electricity from
your body.
●
Before installing an internal accessible drive, see the manual for the
accessible drive.
●
When forcing an accessible drive into a server, be careful so as not
to pinch the cable etc. connected to an accessible drive.
●
Follow the safety instructions in chapter "Important information" on
page 43.
12.3.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Main steps: Phillips PH0 / (+) No. 0 screw driver
Field Replaceable Units (FRU)
Average task duration: 5 minutes
