Fujitsu PRIMERGY RX100 S7 - Removing the Defective SGPIO Cable

RX100 S7 Upgrade and Maintenance Manual 407
Cables
5. "Opening the server" on page 64
16.6.3 Removing the defective SGPIO cable
Figure 288: Disconnecting the SGPIO cable from the SAS/SATA backplane
Ê Disconnect the SGPIO cable from the SAS/SATA backplane.
Figure 289: Disconnecting the SGPIO cable from the system board
Ê Disconnect the SGPIO cable from the system board.
Ê Remove the SGPIO cable from the cable clamp (see circle).
