RX100 S7 Upgrade and Maintenance Manual 189
Expansion cards and backup units
Figure 100: Fastening the slot bracket - D2755
Ê Fasten the slot bracket to the controller with two M3 x 4.5 mm screws.
Figure 101: Assembled network adapter D2755
