GBC AdvancedPunch Pro Service Manual

GBC AdvancedPunch Pro 09/11/2018 General Procedures and Information
6-81
Refer to the electrical wiring information and to Parts List PL 3.7, Frame
Assembly (page 7 of 10) Sensors, when reading the following material on
Inputs and Output signals.
Table 6.1 Input Devices
Input
Type
Function
Sensor S1
Optical
Entrance Sensor
Sensor S2
Optical
Entrance Idler Panel Sensor
Sensor S3
Optical
Entrance Idler Panel Sensor
Sensor S4
Optical
Entrance Idler Panel Sensor
Sensor S5
Optical
Accel Sensor
Sensor S6
Circuit Board
Skew Board Sensor
Sensor S7
Circuit Board
Skew Board Sensor
Sensor S8
Circuit Board
Skew Board Sensor
Sensor S9
Circuit Board
Skew Board Sensor
Sensor S10
Circuit Board
Skew Board Sensor
Sensor S11
Circuit Board
Alignment Sensor
Sensor S12
Circuit Board
Alignment Sensor
Sensor S13
Circuit Board
Alignment Sensor
Sensor S14
Circuit Board
Alignment Sensor
Sensor S15
Circuit Board
Alignment Sensor
Sensor S16
Circuit Board
Backgage Sensor
Sensor S17
Circuit Board
Backgage Sensor
Sensor S18
Circuit Board
Large Mid Punch Backgage Sensor
Sensor S19
Circuit Board
Large Mid Punch Backgage Sensor
Sensor S20
Circuit Board
XL Mid Punch Backgage Sensor
Sensor S21
Circuit Board
XL Mid Punch Backgage Sensor
Sensor S22
Optical
Exit Idler Panel Sensor
Sensor S23
Optical
Exit Idler Panel Sensor
Sensor S24
Optical
Exit Idler Panel Sensor
Sensor S25
Optical
Exit Sensor
Sensor S26
Optical
Bypass Sensor
Input
Type
Function
Sensor S27
Sensor, Vein
Sharp
Bypass Open Sensor
Sensor S28
Optical
Align Home Sensor
Sensor S29
Emitter
Receiver
Chip Tray Full Emitter/Receiver
Solenoid SOL1
Mechanical
Divert Solenoid
Solenoid SOL2
Mechanical
Punch Clutch Solenoid
Solenoid SOL3
Mechanical
Entrance Idler Solenoid
Solenoid SOL4
Mechanical
Entrance Idler Solenoid
Solenoid SOL5
Mechanical
Accel Idler Solenoid
Solenoid SOL6
Mechanical
Exit Idler Solenoid
Solenoid SOL7
Mechanical
Solenoid SOL8
Mechanical
Switch SW1
Mechanical
Punch Door Interlock Switch, no
machine movement if door is open
Switch SW
Mechanical
Chip Tray Home Switch
