Planet SGS-6341-24T4X User Manual

52-4
Switch#debug detail attribute interface Ethernet 1/0/1
52.6 debug aaa detail connection
Command:
debug aaa detail connection
no debug aaa detail connection
Function:
Enable the debug information of aaa about connection details; the no operation of this command
will disable that debug information.
Command Mode:
Admin Mode.
Usage Guide:
By enabling the debug information of aaa about connection details, users can check connection
details of aaa, which might help diagnose the cause of faults if there is any.
Example:
Enable the debug information of aaa about connection details.
Switch#debug aaa detail connection
52.7 debug aaa detail event
Command:
debug aaa detail event
no debug detail event
Function:
Enable the debug information of aaa about events; the no operation of this command will disable
that debug information.
Command Mode:
Admin Mode.
Usage Guide:
By enabling the debug information of aaa about events, users can check the information of all kinds
of event generated in the operation process of Radius protocol, which might help diagnose the
cause of faults if there is any.
Example:
Enable the debug information of aaa about events.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
