Planet SGS-6341-24T4X User Manual

52-6
Global Mode.
Usage guide:
The source IP address must belongs to one of the IP interface of the switch, otherwise an failure
message of binding IP address will be returned when the switch send RADIUS packet. We suggest
using the IP address of loopback interface as source IP address, it avoids that the packets from
RADIUS server are dropped when the interface link-down.
Example:
Configure the source ip address of RADIUS packet as 192.168.2.254.
Switch#radius nas-ipv4 192.168.2.254
52.10 radius nas-ipv6
Command:
radius nas-ipv6 <ipv6-address>
no radius nas-ipv6
Function:
Configure the source IPv6 address for RADIUS packet sent by the switch. The no command deletes
the configuration.
Parameter:
<ipv6-address> is the source IPv6 address of the RADIUS packet, it must be a valid unicast IPv6
address.
Default:
No specific source IPv6 address for RADIUS packet is configured, the IPv6 address of the interface
from which the RADIUS packets are sent is used as source IPv6 address of RADIUS packet.
Command mode:
Global Mode.
Usage guide:
The source IPv6 address must belongs to one of the IPv6 interface of the switch, otherwise a failure
message of binding IPv6 address will be returned when the switch send RADIUS packet. We
suggest using the IPv6 address of loopback interface as source IPv6 address, it avoids that the
packets from RADIUS server are dropped when the interface link-down.
Example:
Configure the source ipv6 address of RADIUS packet as 2001:da8:456::1.
Switch#radius nas-ipv6 2001:da8:456::1

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
