Planet SGS-6341-24T4X User Manual

69-2
Example:
To enable the debug switch of displaying local time adjust information.
Switch# debug ntp adjust
69.3 debug ntp authentication
Command:
debug ntp authentication
no debug ntp authentication
Function:
To display NTP authentication information, the no form command disabled the switch of displaying
NTP authentication information.
Default:
Disabled.
Command Mode:
Admin Mode.
Usage Guide:
To display NTP authentication information, if the switch is enabled, and if the packets schlepped
authentication information when the packet in sending or receiving process, then the key identifier
will be printed out.
Example:
To enable the switch of displaying NTP authentication information.
Switch# debug ntp authentication
69.4 debug ntp events
Command:
debug ntp events
no debug ntp events
Function:
To enable/disable debug switch of displaying NTP event.
Default:
Disable the debug switch of displaying NTP event.
Command Mode:
Admin Mode.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
