Planet SGS-6341-24T4X User Manual

26-34
Command:
next-server <address1>[<address2>[…<address8>]]
no next-server
Function:
Sets the server address for storing the client import file; the “no next-server” command cancels the
setting.
Parameters:
<address1>…<address8> are IP addresses, in the decimal format.
Command Mode:
DHCP Address Pool Mode
Usage Guide:
This command configures the address for the server hosting client import file. This is usually used
for diskless workstations that need to download configuration files from the server on boot up. This
command is used together with “bootfile”.
Example:
Setting the hosting server address as 10.1.128.4.
Switch(dhcp-1-config)#next-server 10.1.128.4
26.1.25 option
Command:
option <code> {ascii <string> | hex <hex> | ipaddress <ipaddress>}
no option <code>
Function:
Sets the network parameter specified by the option code; the “no option <code>“command
cancels the setting for option.
Parameters:
<code> is the code for network parameters;
<string> is the ASCII string up to 255 characters;
<hex> is a value in Hex that is no greater than 510 and must be of even length;
<ipaddress> is the IP address in decimal format, up to 63 IP addresses can be configured.
Command Mode:
DHCP Address Pool Mode
Usage Guide:
The switch provides common commands for network parameter configuration as well as various
commands useful in network configuration to meet different user needs. The definition of option
code is described in detail in RFC2123.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
