Planet SGS-6341-24T4X User Manual

26-33
DHCP Address Pool Mode
Usage Guide:
If client node type is to be specified, it is recommended to set the client node type to h-node that
broadcasts after point-to-point communication.
Example:
Setting the node type for client of pool 1 to broadcasting node.
Switch(dhcp-1-config)#netbios-node-type b-node
26.1.23 network-address
Command:
network-address <network-number> [<mask> | <prefix-length>]
no network-address
Function:
Sets the scope for assignment for addresses in the pool; the “no network-address” command
cancels the setting.
Parameters:
<network-number> is the network number;
<mask> is the subnet mask in the decimal format;
<prefix-length> stands for mask in prefix form. For example, mask 255.255.255.0 in prefix is “24”,
and mask 255.255.255.252 in prefix is “30”. Note: When using DHCP server, the pool mask should
be longer or equal to that of layer 3 interface IP address in the corresponding segment.
Default:
If no mask is specified, default mask will be assigned according to the address class.
Command Mode:
DHCP Address Pool Mode
Usage Guide:
This command sets the scope of addresses that can be used for dynamic assignment by the DHCP
server; one address pool can only have one corresponding segment. This command is exclusive
with the manual address binding command “hardware address” and “host”.
Example:
Configuring the assignable address in pool 1 to be 10.1.128.0/24.
Switch(dhcp-1-config)#network-address 10.1.128.0 24
26.1.24 next-server

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
