MAC means VLAN MAC address.
The compatible remote-id format with HP manufacturer defined as below:
Remote option
2
4
IP
1 byte 1 byte
4 byte
type
Length
IP means the primary IP address of layer 3 interface where DHCP packets from.
Example:
Set remote-id of Relay Agent option82 as the compatible format with HP manufacturer.
Switch(config)#ip dhcp relay information option remote-id format vs-hp
28.6 ip dhcp relay information option self-defined
remote-id
Command:
ip dhcp relay information option self-defined remote-id {hostname | mac | string WORD}
no ip dhcp relay information option self-defined remote-id
Function:
Set creation method for option82, users can define the parameters of remote-id suboption by
themselves.
Parameters:
WORD the defined character string of remote-id by themselves, the maximum length is 64.
Command Mode:
Global Mode
Default:
Using standard method.
User Guide:
After configure this command, if users do not configure remote-id on interface, it will create
remote-id suboption for option82 according to self-defined method. For mac, use the format such as
00-02-d1-2e-3a-0d if it is filled to packets with ascii format, but hex format occupies 6 bytes. Each
option will be filled to packets according to the configured order of the commands and divide them
with delimiter (delimiter is ip dhcp relay information option delimiter configuration).
Example:
Set self-defined method and character string of remote-id suboption are hostname and abc

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
