Planet SGS-6341-24T4X User Manual

30-103
Parameters:
standard means the standard format of VLAN name and physical port name, such as
Vlan2+Ethernet1/0/12. <circuit-id> means the circuit-id content of option 82 specified by users, its
length can not exceed 64 characters.
Command Mode:
Port Mode
Default:
Use standard format to set circuit-id.
Usage Guide:
The additive option 82 needs to associate with third-party DHCP server, it is used to specify the
circuit-id content by user when the standard circuit-id format can not satisfy server’s request.
Example:
Set the suboption circuit-id of DHCP option82 as P2.
Switch(config)#ip dhcp snooping information option subscriber-id P2
30.25 ip dhcp snooping information option
subscriber-id format
Command:
ip dhcp snooping information option subscriber-id format {hex | acsii | vs-hp}
Function:
This command is used to set subscriber-id format of DHCP snooping option82.
Parameters:
hex means that subscriber-id is VLAN and port information with hexadecimal format, acsii means
that subscriber-id is VLAN and port information with ACSII format. vs-hp means that subscriber-id is
compatible with the format of HP manufacturer.
Command Mode:
Global mode
Default:
ascii.
User Guide:
VLAN and port information with ASCII format, such as Vlan1+Ethernet1/0/11, VLAN and port
information with hexadecimal format defined as below:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
