Planet SGS-6341-24T4X User Manual

30-104
1
8
0
6
VLAN
Slot
Module
Port
1 byte 1 byte 1 byte 1 byte 2 byte 1 byte 1 byte 2 byte
Suboption
type
Length
Circuit
ID type
Length
VLAN field fill in VLAN ID. For chassis switch, Slot means slot number, for box switch, Slot is 1;
default Module is 0; Port means port number which begins from 1.
The compatible subscriber-id format with HP manufacturer defined as below:
1 2
Port
1 byte 1 byte
2 byte
Suboption
type
Length
Port means port number which begins from 1.
Example:
Set subscriber-id format of DHCP snooping option82 as hexadecimal format.
Switch(config)#ip dhcp snooping information option subscriber-id format hex
30.26 ip dhcp snooping limit-rate
Command:
ip dhcp snooping limit-rate <pps>
no ip dhcp snooping limit-rate
Function:
Set the DHCP message rate limit
Parameters:
<pps>: The number of DHCP messages transmitted in every minute, ranging from 0 to 100. Its
default value is 100. 0 means that no DHCP message will be transmitted.
Command Mode:
Globe mode
Default Settings:
The default value is 100.
Usage Guide:
After enabling DHCP snooping, the switch will monitor all the DHCP messages and implement
software transmission. The software performance of the switch is relative to the type of the switch, its

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
