30-108
interface trust action recovery alarm num bind num
--------------- --------- --------- ---------- --------- ----------
Ethernet1/0/1 trust none 0second 0 0
Ethernet1/0/2 untrust none 0second 0 0
Ethernet1/0/3 untrust none 0second 0 0
Ethernet1/0/4 untrust none 0second 0 1
Ethernet1/0/5 untrust none 0second 2 0
Ethernet1/0/6 untrust none 0second 0 0
Ethernet1/0/7 untrust none 0second 0 0
Ethernet1/0/8 untrust none 0second 0 1
Ethernet1/0/9 untrust none 0second 0 0
Ethernet1/0/10 untrust none 0second 0 0
Ethernet1/0/11 untrust none 0second 0 0
Ethernet1/0/12 untrust none 0second 0 0
Ethernet1/0/13 untrust none 0second 0 0
Ethernet1/0/14 untrust none 0second 0 0
Ethernet1/0/15 untrust none 0second 0 0
Ethernet1/0/16 untrust none 0second 0 0
Ethernet1/0/17 untrust none 0second 0 0
Ethernet1/0/18 untrust none 0second 0 0
Ethernet1/0/19 untrust none 0second 0 0
Ethernet1/0/20 untrust none 0second 0 0
Ethernet1/0/21 untrust none 0second 0 0
Ethernet1/0/22 untrust none 0second 0 0
Ethernet1/0/23 untrust none 0second 0 0
Ethernet1/0/24 untrust none 0second 0 0
Displayed Information
Explanation
DHCP Snooping is enable
Whether the DHCP Snooping is globally enabled or
disabled.
DHCP Snooping binding arp
Whether the ARP binding function is enabled.
DHCP Snooping maxnum of action info
The number limitation of port defense actions
DHCP Snooping limit rate
The rate limitation of receiving packets
switch ID The switch ID is used to identify the switch, usually using
the CPU MAC address.
DHCP Snooping droped packets The number of dropped messages
when the received
DHCP messages exceeds the rate limit.
discarded packets
The number of discarded packets caused by the
