Planet SGS-6341-24T4X User Manual

30-109
communication failure within the system. If the CPU of the
switch is too busy to schedule the DHCP SNOOPING task
and thus can not handle the received DHCP messages,
such situation might happen.
DHCP Snooping alarm count:
The number of alarm information.
binding count
The number of binding information.
expired binding
The number of binding information which is already
expired but has n
ot been deleted. The reason why the
expired information is not deleted immediately might be
that the switch needs to notify the helper server about the
information, but the helper server has not acknowledged it.
request binding
The number of REQUEST information
interface
The name of port
trust
The truest attributes of the port
action
The automatic defense action of the port
recovery
The automatic recovery time of the port
alarm num
The number of history records of the port automatic
defense actions
bind num
The number of port-relative binding information.
switch#show ip dhcp snooping int Ethernet1/0/1
interface Ethernet1/0/1 user config:
trust attribute: untrust
action: none
binding dot1x: disabled
binding user: disabled
recovery interval:0(s)
Alarm info: 0
Binding info: 0
Expired Binding: 0
Request Binding: 0
Displayed Information
Explanation

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
