Planet SGS-6341-24T4X User Manual

35-189
Switch#config terminal
Switch(config)#router ospf 100
Switch(config-router)#area 0.0.0.51 nssa
Switch(config-router)#area 3 nssa default-information-originate metric 34 metric-
type 2
translator-role candidate no-redistribution
35.5 area range
Command:
area <id> range <address> [advertise| not-advertise| substitute]
no area <id> range <address>
Function:
Aggregate OSPF route on the area border. The “no area <id> range <address>“cancels this
function.
Parameter:
<id> is the area number which could be digits ranging between 0～4294967295, and also as an IP
address.
<address>=<A.B.C.D/M> specifies the area network prefix and its length.
advertise: Advertise this area, which is the default.
not-advertise : Not advertise this area.
substitute= substitute <A.B.C.D/M>: advertise this area as another prefix.
<A.B.C.D/M>: Replace the network prefix to be advertised in this area.
Default:
Not set.
Command Mode:
OSPF protocol mode
Usage Guide:
Use this command to aggregate routes inside an area. If the network IDs in this area are not
configured continuously, a summary route can be advertised by configuring this command on ABR.
This route consists of all single networks belong to specific range.
Example:
Switch#config terminal
Switch(config)# router ospf 100
Switch(config-router)# area 1 range 192.16.0.0/24

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
