Planet SGS-6341-24T4X User Manual

35-190
35.6 area stub
Command:
area <id> stub [no-summary]
no area <id> stub [no-summary]
Function:
Define a area to a stub area. The “no area <id> stub [no-summary]” command cancels this
function.
Parameter:
<id> is the area number which could be digits ranging between 0～4294967295, and also as an IP
address.
no-summary: The area border routes stop sending link summary announcement to the stub area.
Default:
Not defined.
Command Mode:
OSPF protocol mode
Usage Guide:
Configure area stub on all routes in the stub area. There are two configuration commands for the
routers in the stub area: stub and default-cost. All routers connected to the stub area should be
configured with area stub command. As for area border routers connected to the stub area, their
introducing cost is defined with area default-cost command.
Example:
Switch # config terminal
Switch (config)# router ospf 100
Switch (config-router)# area 1 stub
Related Command:
area default-cost
35.7 area virtual-link
Command:
area <id> virtual-link A.B.C.D {AUTHENTICATION |AUTH_KEY | INTERVAL}
no area <id> virtual-link A.B.C.D [AUTHENTICATION | AUTH_KEY | INTERVAL]
Function:
Configure a logical link between two backbone areas physically divided by non-backbone area. The
“no area <id> virtual-link A.B.C.D [AUTHENTICATION | AUTH_KEY | INTERVAL]” command

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
