Planet SGS-6341-24T4X User Manual

37-289
{<ip-address>|<TAG>} capability orf prefix-list {<both>|<send>|<receive>}” command set to
not perform the negotiation.
Parameter:
<ip-address>: Neighbor IP address.
<TAG>: Name of peer group.
Default:
ORF capability not configured.
Command Mode:
BGP route mode and address-family mode
Usage Guide:
This is an extended BGP capability. With this configuration supported capabilities by both side will
be negotiated in the OPEN messages, and the partner will respond if this capability is supported by
the partner and send NOTIFICATION if not. The originating side will then send an OPEN excluded
the capability to reestablish the connection. With this capability, the side configured with in prefix-list
filter rules will transmit its own filter rules to the peer, the peer group will apply this rule as its own out
rules, so to avoid sending route which will be denied by the partner.
Example:
Set to perform the out route filter capability negotiation with neighbor 10.1.1.66.
Switch(config-router)#neighbor 10.1.1.66 capability orf prefix-list both
Relevant Commands:
neighbor capability, no neighbor capability
37.49 neighbor collide-established
Command:
neighbor {<ip-address>|<TAG>} collide-established
no neighbor {<ip-address>|<TAG>} collide-established
Function:
Enable the collision check and settlement in the TCP connection collision. The “no neighbor
{<ip-address>|<TAG>} collide-established” command disables the TCP connection collision
settlement.
Parameter:
<ip-address>: Neighbor IP address.
<TAG>: Name of the peer.
Default:
Disabled and Unavailable.
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
