Planet SGS-6341-24T4X User Manual

37-313
Example:
Switch(config-router)#neighbor 10.1.1.66 weight 500
37.82 network (BGP)
Command:
network <ip-address/M> [route-map <WORD>] [backdoor]
no network <ip-address/M> [route-map <WORD>] [backdoor]
Function:
Configure the BGP managed network, the route map specified in network application, or set the
“back door” for the network. The “no network <ip-address/M> [route-map <WORD>] [backdoor]”
command cancels this configuration.
Parameter:
<ip-address/M>: Network prefix identifier
<WORD>: Name of route-map
Command Mode:
BGP route mode
Usage Guide:
As for BGP routes, specify the route through which the BGP advertisements go. With the network
defined by this command, the peer will be spreaded into the route map of the neighbor even if there
is no route locally. Using the attribute specified in the network application through route map, when
specifying the route comes from EBGP or inside the network through back door parameters, the
inside route will be the optimized route even if the external route is of shorter distance.
Example:
Switch(config-router)# network 172.16.0.0/16
37.83 redistribute (BGP)
Command:
redistribute <ROUTES> [route-map <WORD>]
no redistribute <ROUTES> [route-map <WORD>]
Function:
Set the BGP to redistribute route from other modes into BGP. The “no redistribute <ROUTES>
[route-map <WORD>]” command cancels this configuration.
Parameter:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
