Planet SGS-6341-24T4X User Manual

37-314
<ROUTES>: Route source or protocol, including: connected, ISIS, kernel, OSPF, RIP, static, etc.
<WORD>: Name of route map.
Command Mode:
BGP Route Mode.
Usage Guide:
Route from other ways will be distributed into the BGP route table with this command and
transmitted to the neighbors.
Example:
The static route is introduced into BGP with this configuration and advertised to the neighbors.
Example:
Switch(config-router)# redistribute static
37.84 redistribute ospf
Command:
redistribute ospf [<process-id>] [route-map<word>]
no redistribute ospf [<process-id>]
Function:
To redistribute routing information form OSPF to BGP. The no form of this command will remove the
configuration.
Parameters:
process-id is the process ID of the OSPF, limited between 1 and 65535. If no process id is
specified, the default process id will be used.
route-map<word> is the pointer to the introduced routing map.
Default:
Not redistributed by default.
Command Mode:
BGP Configuration Mode.
Example:
To redistribute routing of OSPF v2 to BGP (as number is 1).
Switch(config)#router bgp 1
Switch (config-router)#redistribute ospf 2

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
