Planet SGS-6341-24T4X User Manual

44-78
Interface Configuration Mode
Usage Guide:
The routing information in DVMRP report messages includes a groupsource network and metric list.
After configuring interface DVMRP report message metric value, it makes all received routing entriy
from the interface adding configured interface metric value as new metric value of the routing. The
metric value applies to calculate posion reverse, namely ensuring up-downstream relations. If the
metric value of some route on the switch is not less than 32, it explains the route can be reach. If it is
downstream of some route after calculation and judgment, it will transmit report message included
the route to upstream. The route metric increases 32 based on original value in order to indicate
downstream itself.
Example:
Configure interface DVMRP report message metric value: 2
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ip dvmrp metric 2
44.7.4 ip dvmrp multicast-routing
Command:
ip dvmrp multicast-routing
no ip dvmrp multicast-routing
Function:
Globally enable DVMRP protocol; the “no ip dvmrp multicast-routing” command globally disenables
DVMRP protocol
Default:
Default
Command Mode:
Global Mode
Usage Guide:
Dvmrp multicast-protocol can enable after globally execute the command
Example:
Switch (config)#ip dvmrp multicast-routing
44.7.5 ip dvmrp output-report-delay
Command:
ip dvmrp output-report-delay <delay_val> [<burst_size>]

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
