Planet SGS-6341-24T4X User Manual

44-85
<destination-wildcard>}|{host-destination <destination-host-ip>}|any-destination}” command
deletes the access-list.
Parameter:
<6000-7999>: destination control access-list number.
{deny|permit}: deny or permit.
<source>: multicast source address.
<source-wildcard>: multicast source address wildcard character..
<source-host-ip>: multicast source host address.
<destination>: multicast destination address.
<destination-wildcard>: multicast destination address wildcard character.
<destination-host-ip>: multicast destination host address
Command Mode:
Global Mode
Usage Guide:
ACL of Multicast destination control list item is controlled by specifical ACL number from 6000 to
7999, the command applies to configure this ACL. ACL of Multicast destination control only needs to
configure source IP address and destination IP address controlled (group IP address), the
configuration mode is basically the same to other ACLs, and use wildcard character to configure
address range, and also specify a host address or all address. Remarkable, “all address” is
224.0.0.0/4 according to group IP address, not 0.0.0.0/0 in other access-list.
Example:
Switch(config)#access-list 6000 permit ip 10.1.1.0 0.0.0.255 232.0.0.0 0.0.0.255
Switch(config)#
44.8.2 access-list (Multicast Source Control)
Command:
access-list <5000-5099> {deny|permit} ip {{<source> <source-wildcard>}|{host
<source-host-ip>}|any-source} {{<destination> <destination-wildcard>}|{host-destination
<destination-host-ip>}|any-destination}
no access-list <5000-5099> {deny|permit} ip {{<source> <source-wildcard>}|{host
<source-host-ip>}|any} {{<destination> <destination-wildcard>}|{host-destination
<destination-host-ip>}|any-destination}
Function:
Configure source control multicast access-list; the “no access-list <5000-5099> {deny|permit} ip
{{<source> <source-wildcard>}|{host <source-host-ip>}|any-source} {{<destination>
<destination-wildcard>}|{host-destination <destination-host-ip>}|any-destination}” command

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
