Planet SGS-6341-24T4X User Manual

44-100
multicast group, the value of timer is selected random from 0 to maximum response time, the host
will transmit member report message of the multicast group. Reasonable configuring maximum
response time, it can make host quickly response query message. The router can also quickly
grasp the status of multicast group member.
Example:
configure the maximum period responding to the IGMP query messages to 20s
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ip igmp query- max-response-time 20
44.9.11 ip igmp query-timeout
Command:
ip igmp query-timeout <time_val>
no ip igmp query-timeout
Function:
Configure IGMP query timeout of interface; the “no ip igmp query-timeout” command restores
default value.
Parameter:
<time_val> is IGMP query-timeout, value range from 60s to 300s.
Default:
255s.
Command Mode:
Interface Configuration Mode
Usage Guide:
When multi-running IGMP switches are exist on sharing network, a switch will be voted as query
processor on the sharing network, and other switches will be a timer monitoring the state of query
processor; It still does not receive query message transmitting by query processor over query
time-out, thus it re-votes another switch as new query processor.
Example:
Configure timeout of IGMP query message on interface to 100s.
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ip igmp query-timeout 100
44.9.12 ip igmp robust-variable
Command:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
