Planet SGS-6341-24T4X User Manual

45-59
Command:
ipv6 mld immediate-leave group-list {<acl-name>}
no ipv6 mld immediate-leave
Function:
Configure MLD to work in the immediate leave mode, that’s when the host sends a membership
qualification report that equals to leave a group, the router doesn’t send query and consider there is
no this group’s member in the subnet. The “no ipv6 mld immediate-leave” command cancels the
immediate leave mode.
Parameter:
<acl-name> is the name of IPv6 access-list
Default:
Do not configure immediate-leave group
Command Mode:
Interface Configuration Mode
Usage Guide:
This command is used only when there is only one host in the subnet.
Example:
Configure access-list”aclv6”as immediate leave mode.
Switch(Config-if-Vlan1)#ipv6 mld immediate-leave group-list aclv6
45.7.6 ipv6 mld join-group
Command:
ipv6 mld join-group <address>
no ipv6 mld join-group <address>
Function:
Configure the interface to join in certain multicast group; the “no ipv6 mld join-group <address>”
command cancels joining certain multicast group.
Parameter:
<address> is a valid IPv6 multicast address
Default:
No multicast group joined by factory default
Command Mode:
Interface Configuration Mode
Usage Guide:
The address range of the IPv6 multicast is FFxy::/8, however the (FF02::/16) is permanent
addresses which can not be joined in.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
