Planet SGS-6341-24T4X User Manual

45-60
Example:
Join the interface vlan2 in multicast group with multicast address of ff1e::1:3.
Switch(config)#interface vlan 2
Switch(Config-if-Vlan2)#ipv6 mld join-group ff1e::1:3
45.7.7 ipv6 mld join-group mode source
Command:
ipv6 mld join-group <X:X::X:X> mode <include|exclude> source <.X:X::X:X>
no ipv6 mld join-group <X:X::X:X> source <.X:X::X:X>
Function:
Configure the sources of certain multicast group which the interface join in. Note: because of the
client group has got only INLCUDE and EXCLUDE modes, if the source mode is not in accordance
with current mode configured, the group mode will be changed and the original sources of the other
modes configured will be cleared permanently; the “no” form of this command cancels joining
certain group.
Parameter:
<X:X::X:X> is a valid IPv6 multicast address
<include|exclude>: joining mode
<.X:X::X:X>: source list, configure several sources is allowed.
Default:
No multicast group to be joined by factory default
Command Mode:
Interface Configuration Mode
Usage Guide:
The address range of the IPv6 multicast is FFxy::/8, however the (FF02::/16) is permanent
addresses which can not be joined in. As for sources with mode same as the original one, the
source will be added, while for those with different modes, the original sources will be cleared.
Example:
Join vlan2 in multicast group with multicast address of ff1e::1:3, with sources 2003::1 and 2003::2 in
INCLUDE mode.
Switch(config)#interface vlan 2
Switch(Config-if-Vlan2)#ipv6 mld join-group ff1e::1:3 mode include source 2003::1 2003::2
45.7.8 ipv6 mld last-member-query-interval

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
