48-17
Status Authorized
Port-control Auto
Supplicant ,A8-F7-E0-FE-2E-D3
Authenticator State Machine
State Authenticated
Backend State Machine
State Idle
Reauthentication State Machine
State Stop
Displayed information Explanation
Global 802.1x Parameters Global 802.1x parameter information
reauth-enabled Whether re-authentication is enabled or not
reauth-period Re-authentication interval
quiet-period Silent interval
tx-period EAP retransmission interval
max-req EAP packet retransmission interval
authenticator mode Switch authentication mode
Mac Filter Enables dot1x address filter or not
MacAccessList Dot1x address filter table
dot1x-EAPoR Authentication method used by the switch (EAP relay, EAP
local end)
dot1x-privateclient Whether the switch supports the privateclient
802.1x is enabled on ethernet
Ethernet1/0/1
Indicates whether dot1x is enabled for the port
Authentication Method: Port authentication method (MAC-based, port-based,
user-based)
Status Port authentication status
Port-control Port authorization status
Supplicant Authenticator MAC address
Authenticator State Machine Authenticator state machine status
Backend State Machine Backend state machine status
Reauthentication State Machine Re-authentication state machine status
48.25 user-control limit ipv4
Command:
user-control limit ipv4 <count>
