Phaser 6300/6350/6360 Color Laser Printer Service Manual I – 5
I
IDE disk error, 4-4
image intensity, 6-2
Image Processor Board, 2-45
connectors, 10-7
CPU interrupts error, 4-5
fault isolation, 4-5
location, 2-45
NVRAM
location
, 8-99
part number, 9-35
removal, 8-99
NVRAM (EEPROM) error, 4-5
part number, 9-35
removal, 8-99
reseat controller board error, 4-7
reset, A-21
wiring diagram, 10-27
image size, 5-8
Imaging Unit, 2-42
cleaning, 7-3
components, 2-42
harness assembly, 9-29
install or reseat error, 3-7
life count, 1-12
location, 1-10
non-Xerox imaging unit error, 3-6
part number, 9-27
precautions, 8-10
removal, 8-7
replace imaging unit error, 3-6
view life counts, 6-9
waste toner reservoir, 2-5
wiring, 10-25
Interlock Switch, 4-15
connector location, 10-6
location, 2-20
operation, 4-15
part number, 9-35
removal, 8-102
testing, A-17
wiring, 10-17
J
jam error log, 3-3
format, 3-3
jam errors, 3-6
jam history, 3-3
job collation, 1-2
L
Laser Unit, 2-42
cleaning, 7-4
components, 2-42
failure error, 3-7
operation, 2-7
part number, 9-27
precautions, 8-77
removal, 8-77
wiring diagram, 10-23
LED
blink patterns
, 4-5
color definitions, 1-6
Health LED, 4-2
Link
part number
, 9-19
removal, 8-60
Long-Life Maintenance Kit, 7-4
contents, 9-62
installation, 7-4
life count, 1-12
part number, 9-58
replace maintenenace kit error, 3-8
reset counter, 6-7
Low Paper Sensor, 2-41
connector location, 10-8
part number, 9-13
removal, 8-32
LVPS, 2-46
connectors, 10-6
location, 2-45
overcurrent protection, 4-14
overvoltage protection, 4-14
part number, 9-35
removal, 8-100
troubleshooting, 4-15
wiring diagram, 10-17
LVPS Fan, 2-45
connector location, 10-6
control circuit, 4-14
failure error, 3-7
part number, 9-5
removal, 8-104
wiring, 10-17
M
Macintosh printing problems, 4-22
Main Drive Motor, 2-27
connector location, 10-6
drive train, 2-28
motor failure error, 3-8
part number, 9-33
removal, 8-96
wiring, 10-19
margins
adjustment
, 6-2
restore defaults, 6-5
measurement techniques, 3-9
media errors, 3-7
Memory, 1-12
errors, 4-3
location, 2-45
maximum, 1-12
minimum, 1-12
