I – 6 Phaser 6300/6350/6360 Color Laser Printer Service Manual
options, 1-8
POST testing, 4-3
supported types, 1-12
upgrades, 9-59
Menu Map
6300/6350 menu
, A-2
6360 menu, A-4
metered printing, 1-4
Microswitch, 2-18
Mode, A-21
Mode Select Port, A-21
location, 1-7
operation, A-21
wiring, 10-27
modes
print quality
, 2-6
Motor
1100-Sheet Feeder
Drive, 2-50
550-Sheet Feeder
Drive
, 2-55
Developer Drive, 2-23
connector location, 10-6
location, 2-22
motor failure error, 3-8
removal, 8-94
wiring, 10-19
Duplex, 2-34
connector location, 10-5
location, 2-34
removal, 8-59
wiring, 10-19
Fuser, 2-32
connector location, 10-6
location, 2-32
motor failure error, 3-8
removal, 8-97
wiring, 10-19
Main Drive, 2-27
connector location, 10-6
location, 2-22
motor failure error, 3-8
removal, 8-96
wiring, 10-19
testing, A-15
Toner
connector location
, 10-5
drive train, 2-44
location, 2-43
wiring, 10-21
N
network
Apple troubleshooting
, 4-22
Ethernet Port, 1-7
log format, 4-26
logging, 4-26
remote access, 4-26
restore defaults, 6-5
troubleshooting, 4-24
Network Diagnostics, 4-24
No Paper Sensor, 2-40
connector location, 10-8
part number, 9-13
removal, 8-31
testing, A-17
No Toner Sensor, 2-43
connector location, 10-5
part number, 9-31
removal, 8-88
wiring, 10-20
Non-contact Sensor, 2-37
NVRAM
location
, 2-45
POST testing, 4-3
reset postscript, 6-8
save and restore, 6-8
supported types, 1-12
utilities, A-19
O
Option Feeder Harness (OPFPLG)
connector location
, 10-8
part number, 9-11
removal, 8-29
options, 1-8
output tray, 1-2
P
PagePack, 1-4
password, 1-4
PIN, 1-4
Paper Feed Roller, Tray, 8-21
paper guides, 2-39
paper path, 2-16
flow diagram, 2-17
sensing, 2-19
sensor locations, 2-20
Paper Pick Assembly, 2-40
components, 2-40
connector locations, 10-8
operation, 2-40
paper size detection, 2-7
Paper Size Switch
connector location
, 10-8
part number, 9-11
removal, 8-28
size indication, 2-7
Parts Differences, 8-2
personal print, 1-2
photo mode, 2-6
power cord, 9-35
Power On Self Test (POST)
bypass testing
, 4-3
description, 4-3
error indications, 4-3
