Phaser 6300/6350/6360 Color Laser Printer Service Manual I – 7
fault types, 4-3
hard faults, 4-5
error display, 4-5
LED blink patterns, 4-5
types, 4-5
Health LED, 4-2
indicators, 4-2
memory error correction, 4-17
soft faults, 4-4
corrective actions, 4-4
Startup page format, 4-4
types, 4-4
version, 4-2
power requirements, 1-12
power saver mode, 1-14
Power Switch, 2-45
preventative maintenance, 7-4
print quality
analyzing test prints
, 5-8
CMYK test print, 5-5
defect analysis, 5-2
defects by component, 5-3
margins, 5-9
paper tips page, 5-2
registration, 5-9
repeating defects, 5-2
troubleshooting, 5-2
Printer, 1-2
6300/6350 menu map, A-2
6360 menu map, A-4
boot sequence, 4-2
chassis removal, 8-24
cleaning, 7-2
color calibration, 6-2
configurations, 1-3
dimensions, 1-13
error reporting, 3-2
image area, 1-15
memory configurations, 1-8
metered operation, 1-4
operational characteristics, 1-14
operational modes
customer mode
, A-21
service mode, A-21
options, 1-8
paper path, 2-16
power consumption, 1-12
power requirements, 1-12
required minimum clearances, 1-13
sensor types, 2-18
status codes, A-6
view total page count, 6-9
print-quality modes, 2-6
proof print, 1-2
R
Rear Fan, 2-45
connector location, 10-6
control circuit, 4-14
failure error, 3-7
location, 2-45
removal, 8-103
testing, A-15
wiring, 10-17
Rear Panel, 1-7
layout, 1-7
registration, 5-8
color registration page, 6-3
horizontal adjustment, 6-3
restore defaults, 6-4
Registration Chute, 2-31
part number, 9-15
removal, 8-37
Registration Roller, 2-30
components, 2-30
jam error, 3-6
part number, 9-17
removal, 8-41
Registration Sensor, 2-30
actuator removal, 8-38
connector location, 10-7
location, 2-20
part number, 9-15
removal, 8-39
testing, A-17
wiring, 10-26
resolution, 1-14
routine maintenance, 7-4
errors, 3-6
life counts, 1-11
S
screw types, 8-6
secure print, 1-2
Sensor, 2-18
CTD (ADC) Sensor, 2-11
connector location, 10-6
location, 2-21
part number, 9-21
removal, 8-72
testing, A-18
Duplex Jam Sensor, 2-33
location, 2-20
removal, 8-56
testing, A-17
Full Stack Sensor, 2-33
location, 2-20
part number, 9-25
removal, 8-54
testing, A-17
Fuser Exit Sensor, 2-36
location, 2-20
testing, A-17
Low Paper Sensor, 2-41
location, 2-20
part number, 9-13
testing, A-17
microswitch, 2-18
