Printing Output Values in the Echo Window
• Overview
• Entering Values Output to Echo Window
• Opening Echo Window
• Clearing Values Output from Echo Window
Other topics about Operation Basics
Overview
The echo window, which appears in the lower part of the E5071C
measurement screen, can be used to display a message or the return value
(data) of an object.
Entering Values Output to Echo Window
You can use the COM objects listed below to enter values output to the
echo window.
• ECHO
• SCPI.DISPlay.ECHO.DATA
Opening Echo Window
You can use the COM objects listed below to open the echo window.
• SCPI.DISPlay.TABLe.TYPE
• SCPI.DISPlay.TABLe.STATe
Alternatively, you can also open the echo window using the following key
sequence:
Macro Setup > Echo Window (ON)
Clearing Values Output from Echo Window
You can use the COM object shown below to clear values output from the
echo window.
• SCPI.DISPlay.ECHO.CLEar
Alternatively, you can also clear values output from the echo window using
the following key sequence:
Macro Setup > Clear Echo
