E5071C
172
parts Characterization,
Connectors, and Adapter
Description are left blank; if
already used, the stored
contents are displayed.
2 Characterization
Enter the information
(operator, used analyzer,
and so on) when measuring
user characteristics as
necessary.
3 Connectors
Select the connector types of
the adapters for the ECal
module's test ports. Male
and female in the list of
connected types indicate
male and female adapter,
respectively. Select "No
adapter" if no adapter is
used on a port.
4
Adapter
Description
Enter the detailed
information on the adapters
connected to each port as
necessary.
The information you have entered is displayed when checking the user
characteristics information by using the key strokes: Cal > Ecal >
Characterization Info.
d. Click Write.
e. At this time, if user characteristics are already stored for the
specified user number, a dialog appears to confirm overwriting. Click
OK.
a. Although the maximum number of user characteristics
stored to the ECal's memory is usually five, this number
may be limited by memory size because the size of user-
characteristics data is not fixed and increases in
proportion to the number of measurement points. An error
occurs when the Write button is pressed if the total size
added the new user characteristics exceeds this limitation
due to memory size.
