E5071C
2898
ID Bit Switch of E5092A
• Change the ID bit switch setting while the E5071C is turned off.
• Two multiport test set can be controlled from one E5071C by
assigning an ID number (ID 1 or ID 2) on each test set.
• The E5091A (option 009 and 016) and the E5092A (option 020)
can be used at the same time.
Selecting the Configuration of the Multiport Test Set
Select the configuration of the multiport test set you want to set.
Operational Procedure
1. Press System >Multiport Test Set Setup > Test Set 1 or Test Set 2.
2. Click Select Test Set.
3. Select the configuration of the multiport test set from the following
selection:
Test
set
Softkey Configuration
