Controlling Multiport Test Set
2901
Port 1
Selects a test port of the multiport test set connected to the port 1. You
can select the port from A, T1, T2, or T3.
Port 2
Selects a test port of the multiport test set connected to the port 2. You
can select the port from T1, T2, T3, or T4.
Port 3
Selects a test port of the multiport test set connected to the port 3. You
can select the port from R1+, R2+, R3+, or R4+.
Port 4
Selects a test port of the multiport test set connected to the port 4. You
can select the port from R1-, R2-, R3-, or R4-.
When the E5091_16 is Selected
Softkey Function
Port 1
Selects a test port of the multiport test set connected to the port 1. You
can select the port from A1, A2, A3, A4, A, T1, T2, or T3.
Port 2
Selects a test port of the multiport test set connected to the port 2. You
can select the port from B1, B2, B3, B4, T1, T2, T3, or T4.
Port 3
Selects a test port of the multiport test set connected to the port 3. You
can select the port from R1+, R2+, R3+, or R4+.
Port 4
Selects a test port of the multiport test set connected to the port 4. You
can select the port from R1-, R2-, R3-, or R4-.
Port 5
Selects a test port of the switch #13 (SW13). You can select the port
from X1 or X2.
Port 6
Selects a test port of the switch #14 (SW14). You can select the port
from Y1 or Y2.
Port 7
Selects a test port of the switch #15 (SW15). You can select the port
from Z1 or Z2.
• The same test ports cannot be connected to each port. In such
a case, the other test ports settings will be automatically
changed.
When the E5092_16 is Selected
Softkey Function
Port 1
Selects a test port of the multiport test set connected to the port 1. You
can select the port from A1, A2, A3, or A4.
Port 2
Selects a test port of the multiport test set connected to the port 2. You
can select the port from B1, B2, B3, or B4.
Port 3
Selects a test port of the multiport test set connected to the port 3. You
