Agilent Technologies E5071C

E5071C
2902
can select the port from R1+, R2+, R3+, or R4+.
Port 4
Selects a test port of the multiport test set connected to the port 4. You
can select the port from R1-, R2-, R3-, or R4-.
Port 5
Selects a test port of the switch #8 (SW8). You can select the port from
X1 or X2.
Port 6
Selects a test port of the switch #9 (SW9). You can select the port from
Y1 or Y2.
Port 7
Selects a test port of the switch #10 (SW10). You can select the port
from Z1 or Z2.
When the E5092_22 is Selected
Softkey Function
Port 1
Selects a test port of the multiport test set connected to the port 1. You
can select the port from A1, A2, A3, A4, A5,or A6.
Port 2
Selects a test port of the multiport test set connected to the port 2. You
can select the port from A7, A8, A9, A10, or A11.
Port 3
Selects a test port of the multiport test set connected to the port 3. You
can select the port from B1, B2, B3, B4, B5, or B6.
Port 4
Selects a test port of the multiport test set connected to the port 4. You
can select the port from B7, B8, B9, B10, or B11.
When the E5092_28 is Selected
Softkey Function
Port 1
Selects a test port of the switch #1 (SW1). You can select the port from
A, B, C, or D.
Port 2
Selects a test port of the switch #2 (SW2). You can select the port from
A, B, C, or D.
Port 3
Selects a test port of the switch #3 (SW3). You can select the port from
A, B, C, or D.
Port 4
Selects a test port of the switch #4 (SW4). You can select the port from
A, B, C, or D.
Port 5
Selects a test port of the switch #5 (SW5). You can select the port from A
or B.
Port 6
Selects a test port of the switch #6 (SW6). You can select the port from A
or B.
