Controlling Multiport Test Set
2903
Port 7
Selects a test port of the switch #7 (SW7). You can select the port from A
or B.
Port 8
Selects a test port of the switch #8 (SW8). You can select the port from A
or B.
Port 9
Selects a test port of the switch #9 (SW9). You can select the port from A
or B.
Port 10
Selects a test port of the switch #10 (SW10). You can select the port
from A or B.
When the E5092_X10 is Selected
Softkey Function
Port 1
Selects a test port of the multiport test set connected to the port 1. You
can select the port from 1, 3, 5, or 7.
Port 2
Selects a test port of the multiport test set connected to the port 2. You
can select the port from 2, 4, 6, or 8.
Port 3
Selects a test port of the multiport test set connected to the port 3. You
can select the port from 2, 4, 6, or 10.
Port 4
Selects a test port of the multiport test set connected to the port 4. You
can select the port from 1, 3, 5, or 9.
Displaying the Properties
By displaying the multiport test set properties shown below, you can obtain
the assignment information of the test ports for each channel. This is
useful when you need to check the test port assignment, for example,
when you perform calibration.
Multiport Test Set properties
