Agilent Technologies E5071C User Manual

Measurement
427
Setting Description Key Operation
Number of traces: 4
Display > Number of Traces > 4
Trace allocation: 4-part split Allocate Traces >
2. Set the measurement parameter (mixed mode S-parameter) and
data format for trace 1.
Setting Description Key Operation
Fixture simulator: ON Analysis > Fixture Simulator >
Fixture Simulator (turns it ON)
Unbalanced-balanced conversion
of trace 1: ON
BalUn (turns it ON)
Measurement parameter: Sds21
Meas > Sds21
