Agilent Technologies E5071C

Measurement
441
Assign test port T1 to port 2. Port2 > T1
Assign test port R1+ to port 3. Port3 > R1+
Assign test port R1- to port 4. Port4 > R1-
4. Assign test ports for channels 2, 3, and 4. Press the Channel Next key
to switch the active channel and then make the same setting of
channel 1.
5. Enable the control of the E5091A.
Setting Description Key Operation
Enable the control of the
E5091A.
Control (set it to ON)
4. Setting Control Line
1. Set the bits of the control line for channel 1.
Setting Description Key Operation
Set channel 1 to the active
channel.
Channel Next
Line 1: Low Control Lines (check only)
Line 2: High Control Lines > Line 1 (set it to
High)
2. Set the control line for channels 2, 3, and 4 according to the same
procedure of channel 1.
5. Setting Sweep Conditions
1. Set the sweep conditions for channel 1.
Setting Description Key Operation
Set channel 1 to the active
channel.
Channel Next
Start frequency: 400 MHz Start > 4 > 0 > 0 > M/u
Stop frequency: 1.4 GHz Stop > 1 > . > 4 > G/n
